Member Products

Products based on SGET Standards

Find the perfect solution to build the Embedded System of your dreams. Browse the growing selection of SGET Member Products to start building your individual embedded solution based on Open Standards. Please use the filters below to see the high-quality products our members provide.

i.MX 8 QuadMax/QuadPlus Qseven Development Kit

2022-11-06T19:24:45+01:00

Manufacturer: iWave Global

The i.MX 8 QM/QP (Quad Max/Quad Plus) SMARC Development platform combines the NXP i.MX 8 QM/QP application processor based SMARC SOM and iWave's Generic SMARC Carrier Card to offer maximum performance with higher efficiency for complex consumer, medical and industrial embedded computing applications. The board is highly packed with all necessary onboard connectors to validate i.MX 8 QM/QP SoC features to the fullest.
i.MX 8 QuadMax/QuadPlus Qseven Development Kit2022-11-06T19:24:45+01:00

i.MX 8 QuadMax/QuadPlus Qseven Module

2022-11-06T19:24:53+01:00

Manufacturer: iWave Global

The i.MX 8 QM/QP(QuadMax/QuadPlus) Qseven System On Module integrates Cortex A72, Cortex A53 & Cortex-M4F Cores, Dual GPU systems, 4K H.265 capable VPU and dual failover-ready display controllers based i.MX 8 QM/QP SoC with on SOM 1000/100/10 Mbps Ethernet PHY, USB 3.0 HUB and IEEE 802.11 a/b/g/n/ac/ax Wi-Fi & BT 5.0 module. The i.MX 8 QM/QP Qseven System on Module is aimed to offer maximum performance with higher efficiency for complex embedded application of consumer, medical and industrial embedded.
i.MX 8 QuadMax/QuadPlus Qseven Module2022-11-06T19:24:53+01:00

i.MX 8M Plus SMARC Module

2022-11-06T19:46:18+01:00

Manufacturer: iWave Global

The i.MX 8M Plus Quad/QuadLite/Dual SMARC System on Module integrates Quad/Dual Cortex A53 @ up to 1.8GHz, NPU with up to 2.3 TOP/s, two camera inputs and a HDR-capable Image Signal Processor (ISP) capable of 375 MPixels/s, H.265 1080p60 decode, 3D and 2D graphic acceleration, HiFi 4 DSP, MIPI DSI, LVDS (4/8- lane), HDMI TX, USB3.0, PCIe Gen3, on SOM Dual 10/100/1000 Mbps Ethernet PHY with TSN support on one port, IEEE 802.11 a/b/g/n/ac Wi-Fi & BT 5.0 module, USB 2.0 Hub and GNSS Module (optional). The i.MX 8M Plus SMARC System on Module is aimed to offer for applications mainly focusing on Machine Learning, NPU and vision system, advanced multimedia and industrial automation with high reliability.
i.MX 8M Plus SMARC Module2022-11-06T19:46:18+01:00

i.MX 8M Quad/QuadLite/Dual SMARC Development Kit

2022-11-06T19:51:15+01:00

Manufacturer: iWave Global

The i.MX 8M Quad/QuadLite/Dual SMARC Development platform combines the NXP’s i.MX 8M Quad/QuadLite/Dual application processor based SMARC SOM and iWave's Generic SMARC Carrier Card to offer consumer, medical and industrial embedded computing & multimedia applications. The board is highly packed with all necessary onboard connectors to validate i.MX 8M Quad/QuadLite/Dual SoC features.
i.MX 8M Quad/QuadLite/Dual SMARC Development Kit2022-11-06T19:51:15+01:00

i.MX 8M Quad/QuadLite/Dual SMARC SOM

2022-11-06T20:24:17+01:00

Manufacturer: iWave Global

The i.MX 8M Quad, Quad Lite, Dual based SMARC System On Module integrates Quad/Dual Cortex A53 @ up to 1.5GHz, H.265 4K60 decode, GC7000 Lite GPU, MIPI CSI, MIPI DSI/Dual LVDS, HDMI2.0 TX, USB3.0, PCIe2.0 with on SOM 10/100/1000 Mbps Ethernet PHY and IEEE 802.11 a/b/g/n/ac/ax* Wi-Fi & BT 5.0 Module. The i.MX 8M SMARC System On Module is aimed to offer applications such as Digital Media Adaptors, HD Digital signage, Industrial HMI, Building Automation, Imaging & Scanning, Audio/Video Streaming devices and Machine Vision.
i.MX 8M Quad/QuadLite/Dual SMARC SOM2022-11-06T20:24:17+01:00
